Product Description
Kirjeldus (eesti keeles)
LOXONE M-Bus Extension on DIN-siinile paigaldatav M-Bus-master kuni 30 M-Bus seadme, nagu gaasi-, vee- või soojusarvestite, lugemiseks. Loetud väärtusi saab kasutada energiahalduseks, tarbimisandmete registreerimiseks ja paljuks muuks.
Omadused:
- Kuni 30 M-Bus seadet
- Siini pikkus kuni 100 m
- Toetab samal siinil erinevaid andmeedastuskiirusi (300–9600 bd)
- Siin-, liin-, täht- või puutopoloogia
- Vastab täielikult standardile EN 13757
- Toetab päringutsükleid alates ühest sekundist
Oluline märkus: energiaettevõtete arvestid toimivad tavaliselt M-Bus-masterina ega ole seetõttu mõeldud lugemiseks Loxone M-Bus Extensioniga, mis töötab samuti masterina (ega ka mõne muu M-Bus lüüsiga). Lisaks ei toeta M-Bus Extension krüpteerimist.
Description (English)
The LOXONE M-Bus Extension is an M-Bus-Master for DIN rail mounting for reading up to 30 M-Bus devices such as gas, water or energy meters. The read values can be used for energy management, consumption data recording and much more.
Features:
- Up to 30 M-Bus devices
- Up to 100m bus length
- Supports different baud rates (300-9600 bd) on the same Bus
- Bus, line, star or tree topology
- Fully compliant with EN13757
- Supports query cycles from one second
Important note: Energy utility meters usually act as M-Bus-Master and are therefore not designed to be read by the Loxone M-Bus Extension, which also works as a Master (or another M-Bus gateway). In addition, the M-Bus Extension does not support encryption.
Tehnilised andmed / Technical data
| Elektrilised andmed / Electrical Specifications | |||||
|---|---|---|---|---|---|
| Toitepinge / Supply voltage | 20 … 28 VDC | ||||
| Energiatarve / Power consumption | 0.6 W (no bus load) 2.9 W (incl. 45 mA bus load) | ||||
| Võimsuskadu max koormusel / Power loss at max. load | 1.3 W (at 45 mA bus load) | ||||
| Liidesed / Interfaces | |||||
| LOXONE Link | Connection with Miniserver | ||||
| M-Bus | M-Bus devices: max. 30 devices Bus length: max. 100 m Bus topologies: Bus, Line, Star, Tree Baud rate: 300 ... 9600 bd (adjustable) Bus voltage: High: 36 V, Low: 24 V Bus load: max. 45 mA / 30 unit loads, lmax: 145 mA (45 mA + 100 mA margin) | ||||
| Keskkonnatingimused / Ambient Conditions | |||||
| Temperatuur / Temperature | -40 … 70 °C / -40 … 158 °F | ||||
| Niiskus / Humidity | max. 95 % RH (non-condensing) | ||||
| Kaitseaste / Ingress protection | IP20 | ||||
| Ühendusklemmid / Connection Terminals | |||||
| Klemmi tüüp / Terminal type |
| ||||
| Juhtme ristlõige / Wire cross-section |
| ||||
| Isolatsiooni eemaldamise pikkus / Stripping length |
| ||||
| Temperatuuritaluvus / Temperature resistance |
| ||||
| Toote omadused / Product Characteristics | |||||
| Paigaldusviis / Mounting type | DIN rail according to EN 50022, 35 mm | ||||
| Värvid / Colours | Black: RAL 9005 | ||||
| Pinnaviimistlus / Finish | Matte | ||||
| Kaal ja mõõtmed / Weight & Dimensions | |||||
| Netokaal / Net weight | 63g | ||||
| Kogukaal / Total weight | 81 g | ||||
| Toote mõõtmed / Product dimensions | 88 x 35.4 x 57 mm / 3.46 x 1.39 x 2.24” (L x W x H), 2 division units | ||||
| Pakendi mõõtmed / Pack size | 121 x 38 x 62 mm / 4.76 x 1.50 x 2.44” (L x W x H) | ||||
| Sertifikaadid ja standardid / Certifications & Standards | |||||
| Standardid / Standards | EN 13757 | ||||
Allikas / Source: LOXONE ametlikud tooteandmed / official product data. Tootekood / Item No.: 100569
