Product Description
Kirjeldus (eesti keeles)
LOXONE AO Extension pakub 4 analoogväljundit 0–10 V. Ideaalne analoogjuhtsignaalide edastamiseks vahemikus 0–10 V. Sellega saab juhtida küttekehi, elektroonilisi liiteseadiseid, pumpasid ja palju muud.
Omadused:
- Hetkeline väljundvool: max 20 mA
- Pidev väljundvool: max 10 mA
- Eraldusvõime: 0,1 V
Pange tähele, et tegemist on juhtsignaaliga. Analoogväljundit võib koormata kuni 20 mA-ga.
Beschreibung (Deutsch)
Die LOXONE AO Extension bietet 4 analoge 0-10-V-Ausgänge. Perfekt zur Übertragung analoger Steuersignale im 0-10-V-Bereich. Damit lassen sich Heizungen, elektronische Vorschaltgeräte, Pumpen und vieles mehr ansteuern.
Merkmale:
- Kurzzeitiger Ausgangsstrom: max. 20 mA
- Dauerausgangsstrom: max. 10 mA
- Auflösung: 0,1 V
Bitte beachten Sie, dass es sich um ein Steuersignal handelt. Der analoge Ausgang darf nur mit maximal 20 mA belastet werden.
Technische Daten
| Elektrische Daten | |
|---|---|
| Versorgungsspannung | 14 … 28 VDC |
| Leistungsaufnahme | typ. 0,11 W, max.1.26 W |
| Verlustleistung bei max. Last | 1,26 W |
| Ausgänge | |
| Analog (4) | Bereich: 0 ... 10 V | Momentan Ausgang: max. 20 mA | dauerhaft Ausgang: max. 10 mA | Auflösung: 0,1 V |
| Schnittstellen | |
| LOXONE Link | Anschluss mit Miniserver |
| Umgebungsbedingungen | |
| Temperatur | 0 … 55 °C / 32 … 131 °F |
| Luftfeuchtigkeit | max. 95 % RH (nicht kondensierend) |
| Schutzart | IP20 |
| Anschlussklemmen | |
| Klemmentyp | 24 VDC & LOXONE Link | Ausgänge | | DG220B | - |
| Leiterquerschnitt | 0,25 … 0,8 mm² / AWG 23 … 18 | 0,14 … 0,5 mm² / AWG 26 … 20 |
| Abisolierlänge | 5 mm / 0.2" | 7 mm / 0.28" |
| Temperaturbeständigkeit | -40 … 105 °C / -40 … 221 °F | -40 … 70 °C / -40 … 158 °F |
| Produkteigenschaften | |
| Montageart | DIN rail gemäß EN 50022, 35 mm |
| Farben | Schwarz: RAL 9005 |
| Oberfläche | Matt |
| Gewicht & Abmessungen | |
| Nettogewicht | 338 g |
| Gesamtgewicht | 412 g |
| Produktabmessungen | 88 x 35,4 x 57 mm / 3,46 x 1,39 x 2.24” (L x W x H), 2 division Einheiten |
| Verpackungseinheit | 121 x 38 x 62 mm / 4,76 x 1,50 x 2.44” (L x W x H) |
| Zertifizierungen & Normen | |
| Zertifizierungen | UL 62368-1 | CSA C22.2#62368-1 |
Quelle: LOXONE ametlikud tooteandmed / official product data. Tootekood / Item No.: 100382
Description (English)
The LOXONE AO Extension provides 4 analog 0-10V outputs. Perfect for transmitting analog control signals in the 0-10V range. This can be used to control heaters, electronic ballasts, pumps and much more.
Features:
- Instantaneous output: max. 20mA
- Continuous output: max. 10mA
- Resolution: 0.1V
Please note that this is a control signal. The analog output may only be loaded with a maximum of 20mA.
Tehnilised andmed / Technical data
| Elektrilised andmed / Electrical Specifications | |||||
|---|---|---|---|---|---|
| Toitepinge / Supply voltage | 14 … 28 VDC | ||||
| Energiatarve / Power consumption | typ. 0.11 W, max.1.26 W | ||||
| Võimsuskadu max koormusel / Power loss at max. load | 1.26 W | ||||
| Väljundid / Outputs | |||||
| Analoog (4) / Analogue (4) | Range: 0 ... 10 V Momentary output: max. 20 mA Continuous output: max. 10 mA Resolution: 0.1 V | ||||
| Liidesed / Interfaces | |||||
| LOXONE Link | Connection with Miniserver | ||||
| Keskkonnatingimused / Ambient Conditions | |||||
| Temperatuur / Temperature | 0 … 55 °C / 32 … 131 °F | ||||
| Niiskus / Humidity | max. 95 % RH (non-condensing) | ||||
| Kaitseaste / Ingress protection | IP20 | ||||
| Ühendusklemmid / Connection Terminals | |||||
| Klemmi tüüp / Terminal type |
| ||||
| Juhtme ristlõige / Wire cross-section |
| ||||
| Isolatsiooni eemaldamise pikkus / Stripping length |
| ||||
| Temperatuuritaluvus / Temperature resistance |
| ||||
| Toote omadused / Product Characteristics | |||||
| Paigaldusviis / Mounting type | DIN rail according to EN 50022, 35 mm | ||||
| Värvid / Colours | Black: RAL 9005 | ||||
| Pinnaviimistlus / Finish | Matte | ||||
| Kaal ja mõõtmed / Weight & Dimensions | |||||
| Netokaal / Net weight | 338 g | ||||
| Kogukaal / Total weight | 412 g | ||||
| Toote mõõtmed / Product dimensions | 88 x 35.4 x 57 mm / 3.46 x 1.39 x 2.24” (L x W x H), 2 division units | ||||
| Pakendi mõõtmed / Pack size | 121 x 38 x 62 mm / 4.76 x 1.50 x 2.44” (L x W x H) | ||||
| Sertifikaadid ja standardid / Certifications & Standards | |||||
| Sertifikaadid / Certifications | UL 62368-1 CSA C22.2#62368-1 | ||||
Allikas / Source: LOXONE ametlikud tooteandmed / official product data. Tootekood / Item No.: 100382
